Weight | 4140 |
---|---|
Concave | Yes |
Deck Width | 140 mm |
Deck Length | 533 mm |
Deck Neck | Welded |
Headset | Integrated |
Headtube angle | N/A |
Headtube height | 105 |
Footspace | 380 |
Deck-end | Box-end |
Deck material | Aluminium |
Heat treatment-Deck | T6 |
Brake type | Flex brake |
Backsweep | No |
Handlebar Width | 560 mm |
Handlebar Height | 710 mm |
Handlebar inner diameter | 28,7 mm |
Handlebar outer diameter | 31,8 |
Handlebar Shape | T |
Slitted | No |
Handlebar material | CrMo |
Heat treatment-Handlebars | T6 |
Fork design | Monoblock |
Thread | Threadless |
Fork Offset | Offset |
Fork material | Aluminium |
Wheel diameter | 110 |
Wheel core design | Spoked |
Wheel core material | Aluminium |
Wheel hub width | 24 mm |
PU width | 24 mm |
PU hardness | 84A |
Deck | Wheel Diameter Compatibility | 100, 110, 115, 120 |
Fork | Wheel Diameter Compatibility | 100, 110, 115, 120 |
Deck | Wheel PU Width Compatibility | 24 mm |
Fork | Wheel PU Width Compatibility | 24 mm |
Bearing precision | ABEC9 |
Compression system | SCS |
Max rider weight | 100 |
Total height | 950 |
SCS / Clamp - Number of bolts | 4 |
Skill | Advanced |
